Black Aerial Bunched Cable

Get a Price/Quote

Black Aerial Bunched Cable Specification

Number of Conductor
2 Core

Cable Type
Aerial Bunched Cable

Usage & Applications
Ideal For Rural Distribution

Conductor Type
Solid

Voltage
660 V

Insulation Material
XLPE

Conductor Material
Aluminium

Jacket Color
Black

Material
Aluminium

Color
Black

Flexible
Moderate flexibility

Flame Retardant
Yes

Phase
Single Phase

Structure
Multi-layered

Typical Installation
Pole-to-pole

Outer Diameter
12-14 mm

RoHS Compliant
Yes

Moisture Resistance
High

UV Stable
Yes

Outer Sheath
PE

Weather Resistant
Yes

Black Aerial Bunched Cable Trade Information

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Black Aerial Bunched Cable

LT XLPE & HT XLPE Aluminum Conductor ABC Cable

Aerial Bunched Cable (ABC) is a very innovative concept for overhead power distribution as compared to the conventional bare conductor overhead distribution system. It is being designed, manufactured & tested conforming to IS: 14255 & other international specifications. It provides higher level of safety and reliability, lower power losses and ultimate system economy by reducing installation, maintenance and operative cost. This system is ideal for rural distribution and it is especially perfect for installation in difficult terrains such as hilly areas, forest areas, coastal areas etc. ABC is also considered to be ideal for power distribution in congested urban areas with narrow lanes and by-lanes. In developing urban complex, ABC is the first choice because of its flexibility for re-routing as demanded by changes in urban development plan.

1.1kv & 11kv (E) XLPE insulated cables available.

HT XLPE cables
LT XLPE cables

Applications

Aerial Bunched Cables are suitable for the following functions mentioned as under:

In theft prone areas
As replacement of bare lines in rural areas, in woods, other localities & narrow street where space is limited
As replacement of bare lines where reliability of supply is of prime importance
As replacement of bare lines where high degree of stability of supply voltage is of importance
In hilly terrains where cost of erection of overhead lines of under ground cable becomes very high
As reinforcement of existing system without increasing voltage
For temporary supplies

Advantages

Aerial Bunched Cables Lines have very high reliability in maintaining services because power and neutral conductors are insulated with the best dielectric. The benefits of using this line are:

Less fault rage on account of good protection against line and ground fault by high winds or falling trees or bird especially in hilly areas & forests as encountered in rural distribution networks.
High insulation resistance to earth in all seasons and polluted atmospheres. Negligible leakage currents and low losses.
Multiple circuits of power and telephone cables could be strung in the same set of poles or any other supports like walls etc.
Better adaptability to "in concurrently with existing over-head bare conductor system without any interference.
High capacitance and low inductance leading to low impedance of lines.
Lower voltage drop, higher current carrying capacitates, vis-a-vis better voltage regulation.
Total lines costs are reduced.
Maintenance is very easy.
Very difficult to tap the ABC cables, thus reducing theft, which leads to lower distribution.
